Product name: U-Shaped cube case（Type B）

Series: D28 & D16

Technical parameter:
U-Shaped cube case——D28 series                            U-Shaped cube case——D16 series
► Be made of welding steel                                                    ► Be made of welding steel
► Hole diameter: 28mm                                                          ► Hole diameter: 16mm
► Hole pitch: 100mm                                                              ► Hole pitch: 50mm
► Material thickness: approx.23mm                                        ► Material thickness: approx.14mm
► Positioning verticality: 0.05-0.1mm                                      ► Positioning verticality: 0.05-0.1mm

Usages:
► For surpporting and positioning larger workpieces.
► Clamps and locators can bolted on it by quick locking pins.
► Extending and connecting several tables when weldments are larger than table.
► Connecting several U-Shaped cube cases to a platform.
► Working with rail base system

Specification as below:
